What Is a Waterproof Linear Light?
A waterproof linear light is a linear lighting fixture with a specially designed housing and sealed interfaces to achieve water and dust resistance. It usually features an aluminum or plastic profile, integrated LED light source, driver, and optical lens, combined with silicone sealing, glue filling, or one-piece molding for reliable waterproof performance.
In commercial and industrial lighting, waterproof linear lights are widely used for:
Outdoor building outlines, façades, and eaves lighting
Shopping Malls & Commercial Corridors
Parking lots, corridors, canopies, and passageways
Swimming pools and other damp areas
Compared with regular LED strips, waterproof linear lights focus more on:
- Stable IP waterproof ratings (such as IP65, IP66, IP67, IP68)
- Long-term thermal management
- UV and corrosion resistance
- Stronger installation and mechanical stability for outdoor and industrial use
| Parameter | Specification |
| Wattage | 15W/20W/30W/40W |
| LED Source | Bridgelux |
| IP | 65 |
| CRI | ≥90 |
| Efficacy | 110-140 lm/W |
| CCT | 3000K / 4000K / 5000K |
| Input Voltage | AC220-240V |
| color | Sand black/Sand white |
| Driver | Lifud/eaglerise |
| Materials | Aluminium diecasting |
| Beam Angle | 15°/24°/36°/55°/60°/80° |
Waterproof Rating & IP Standard Explained
When selecting a waterproof linear light, the IP rating is one of the most critical parameters. An IP rating consists of two digits, such as IP65, IP66, IP67, IP68.
The first digit: dust protection level (0–6)
The second digit: water protection level (0–8)
Typical IP ratings for waterproof linear lighting:
IP65 waterproof linear light: Dust-tight and protected against low-pressure water jets. Suitable for damp indoor areas or semi-outdoor applications.
IP66 waterproof linear light: Withstands powerful water jets, ideal for fully exposed outdoor installations.
IP67 waterproof linear light: Can be temporarily submerged in water, suitable for heavy rain or occasional flooding.
IP68 waterproof linear light: Designed for continuous immersion in water, commonly used for fountains and shallow pools (exact depth depends on the manufacturer’s specification).
Key Advantages of Waterproof Linear LED Lights
Fully dust-proof and resistant to low-pressure water jets, suitable for wet, dusty, and corrosive environments
Supports both surface-mounted installation and embedded installation, which can meet various needs and is suitable for many scenarios.
Switch between 3000K warm white, 4000K natural white, and 5000K daylight white
Contains no harmful substances, is not prone to deformation, and can be recycled and remelted.
How to Choose the Right Waterproof Linear Light?
When selecting waterproof linear LED lighting for your project, consider the following factors:
Environment & IP rating
Fully outdoor: IP66–IP67 or higher
Semi-outdoor / under canopy: IP65
Temporary or permanent immersion: IP67–IP68
Mounting method & dimensions
Check whether it is wall, ceiling, ground, or recessed installation
Measure the available space and choose suitable length and profile size
Brightness & wattage
Define target lux level according to room height and application
Choose appropriate wattage per meter and lumen output
Color temperature & CRIC
ommercial areas: 3000K–4000K, CRI≥80
Industrial & warehouse: 4000K–5000K, CRI≥80/90
Display and retail: CRI≥90 recommended
Control & dimming options
Decide if you need zone dimming, scene control, or integration with building management systems (DALI, 0-10V, DMX, etc.).
Certification & warranty
Look for CE, RoHS, UL, ETL or other regional compliance
Confirm manufacturer’s warranty period and after-sales support
Why Choose Us as Your Waterproof Linear Light Manufacturer?
Professional Commercial Lighting Experience
Professional R&D and custom solutions.
With over 12 years of dedicated experience in commercial lighting manufacturing, our engineering team provides professional R&D support and tailor-made OEM/ODM solutions. Whether you need specific lengths, color temperatures, or unique housing designs, we bring your vision to life.
Fast Response & OEM/ODM Support
Fast and reliable logistics worldwide.
We partner with leading logistics providers to ensure fast, secure, and cost-effective delivery to any destination. From sample orders to bulk container shipments, our global shipping network guarantees your IP65 waterproof linear lights arrive on time.
Custom Lighting Solutions
We provide full customization including size, wattage, CCT, CRI and installation methods to meet different project needs.
High Quality & Certifications
Products are manufactured under strict quality control and comply with international standards such as CE, RoHS and more.
Founded in 2013, Emilux Lighting is a trusted LED lighting manufacturer based in Dongguan, China. We specialize in custom lighting solutions for commercial and architectural projects worldwide. With in-house R&D, strict ISO 9001 quality control, and global project experience, we deliver reliable, high-performance lighting solutions.
FAQ
Yes, OEM/ODM services available with flexible options for length, color temperature, and housing design. Contact us for custom solutions.
Yes, with IP65 rating it is protected against dust and water jets, making it suitable for semi-outdoor applications such as covered walkways, canopies, and parking lots. For full outdoor exposure, we recommend IP66 or IP67 variants – contact us for custom options.
Standard lead time is 15-25 days for bulk orders, depending on quantity and customization. Samples can be delivered within 5-7 days.
Summary & Next Steps
Waterproof linear lights combine high protection, energy efficiency, and flexible installation, making them essential for modern commercial and industrial lighting. By focusing on IP rating, lumen output, CCT, and mounting methods, you can easily find the right waterproof linear LED lighting solution.
If you are looking for a reliable waterproof linear light manufacturer, feel free to check our product pages or contact us directly. Our engineering team will support you with professional selection advice and competitive quotations.
Post time: Apr-24-2026
